Komatsu 951XC-2
Productive final logging harvester with excellent climbing characteristics
Komatsu 951XC-2
Our largest eight-wheeled harvester is a stable and powerful machine, developed especially for harvesting in steep and challenging terrain. Hub reductions, the compact design and a large work area are just a few of the advantages.
- The 951XC produces high tractive force for its size, enabling it to maintain a high speed even in difficult conditions
- 280H crane with 10.3 / 11 m reach
- Choose from our range of options to customise your machine and make your working day even more comfortable and productive
Power
250 kW @ 1 850 rpm
EU Stage V, Tier 4F
Gross lifting torque
285 kNm
210,205 lbf-ft
Max tractive effort
243 kN
54,626 lbf
Weight
From 23775 kg
Specifications
951XC-2
Overview
Dimensions
A. Width
With 710/55x26.5" tyres: 2980 mm (9'9")
B. Length, total
8005 mm
C. Length, front axle to middle joint
1930 mm (6'4")
D. Length, middle joint to rear axle
2150 mm (7'1")
E. Transport height
Straight cab: 3960–4015 mm (depending on options). Transport position (cab max rear tilt, crane forward, light ramp tilted): 3940 mm
F. Ground clearance at steering joint
710 mm
Note
Stated dimensions are nominal and may vary slightly depending on production tolerances and choice of equipment.
Weight
Approximate weight
From 23775 kg
Engine
Type
AGCO Power 75FSTN-D5, 6-cylinder diesel engine with turbo and intercooler
Stroke volume
7.5 l (1.98 gal)
Power
250 kW @ 1 850 rpm (EU Stage V, Tier 4F)
Torque
1 450 Nm @ 1 500 rpm
Fuel tank
466 l
Boom
Model and reach
280H: 10,3 / 11 m (33'9.5" / 36'1")
Gross lifting torque
285 kNm (210,205 lbf-ft)
Gross slewing torque
60 kNm (44,253 lbf-ft)
Heads
Available heads
C124, S132, C144, S172, C164,370E,S162E
Hydraulic system
Flow
485l/min @ 1470 rpm
System pressure
280 bar
Electrical system
Voltage
24 V
Battery capacity
2 x 185 Ah
Generator
200 A
Transmission
Driving speed
0 - approx. 25 km/h (15.6 mph)
Tractive force
243 kN (54,626 lbf)
Notes
General information
The specifications describe possible equipment, not which equipment is standard or optional. Standard and optional equipment varies between countries. Your sales representative has an up-to-date list of what is included. Weights are based on the equipment specified in the basic specification. Specifications and designs are subject to alteration without prior notice.
